| Technical Specifications | |
|---|---|
| Main Frame | 2.0/2.3/2.5/3.0mm thickness, with Powder Coating |
| Drainage System | Φ50mm, PVC drainage tube, Precipitation 16mm/min, No leakage |
| Ceiling | V195 profiled gusset |
| Flooring | Solid wood flooring, thickness 18mm, both sides of the floor of 18mm plywood, PVC floor leather, thickness 2.0mm |
| Interior Description | Inner corner post cover + PVC baseboard |
| Door | Entrance door: broken bridge aluminum folio size >= W1900*H2280mm, tempered glass. Interior door: W780*H2050S indoor high-end steel door. |
| Window | Exterior window: plastic steel sliding window, size: W930mm*H930mm |
| Wall Panel | Flame retardant benzene board, color steel EPS composite board, thickness 75mm, width 950mm, color steel plate thickness 0.3mm, color white gray, flat inside and outside, non-embossed heat insulation board, capacity 12kg/m³ flame retardant |
| Electricity System | LED Round Ceiling Light, 15w/set. Bathroom 12W, national standard socket, single key switch *3, double open, single open Concealed electrical box*1. National standard air switch 220v, 50Hz, CEE industrial plug, 3P32A*1. Entrance line: 3*6 square meters. Air conditioning socket: 3*4 square meters. Ordinary socket: 3*2.5 square meters. Lighting: 2*1.5 square meters. |
| Insulation | 75/100mm glass wool |
| Strengthening Bottom | Galvanized steel square tube can be added up to 14 pieces |
| Resistance | Wind resistance: Grade-11 (0.60kn/m²); Earthquake resistance: Grade-8 |
| Other Details | Fitting + 995 structural silicone sealant + fastening |
