The apple wall is protected and decorated to make it have better aesthetics, durability and functionality.
Heat preservation and insulation, convenient installation, earthquake-resistant, waterproof and moisture-proof.
Excellent anti-corrosion performance, high strength and welding performance.
Double-layer hollow layer design, good sealing performance, heat insulation, sound insulation and noise reduction, good safety performance.
Steel: Q235B Stainless Steel, 2.3mm. Q235B has certain elongation, strength, good toughness and castability, easy to punch and weld, and is widely used in the manufacture of general mechanical parts. It is mainly used for welded structural parts with high quality requirements in construction and bridge engineering.
| Structure Components (Part 1) | Structure Components (Part 2) |
|---|---|
| 1. Bottom frame corners | 12. Top frame secondary beam |
| 2. Bottom frame secondary beam (12*2.0 C-shaped steel) | 13. Top frame long side beam (5635mm) |
| 3. Bottom frame long side beam (5635mm) | 14. Top frame corners |
| 4. Cement fiber board (18mm) | 15. Top frame short side beam (2690mm) |
| 5. 2mm PVC Carpet | 16. Top frame secondary beams |
| 6. Column cover (2600mm) | 17. Top frame long side beam (5635mm) |
| 7. Column (2535mm) | 18. Column (2535mm) |
| 8. UPVC windows + anti-theft net | 19. 50mm diameter drain pipe |
| 9. Ceiling color steel plate | 20. Rock wool sandwich panel (75mm) |
| 10. Glass wool insulation layer | 21. Skirting lines |
| 11. Roofing color steel plate (0.45mm) | 22. Bottom tie beam square tube |
| 23. Bottom frame short side beam (2690mm) |
Cladding (Optional) Timber Style
Window Double Glazed PVC with Screen
Vinyl Flooring
Kitchen cabinet (can be customized)
Bathroom shower, mirror, toilet, washbasin
Power Outlets (US, CE, 3C, UK, AUS, ETC)
Stainless Steel Sink
Located at a strategic hub with transportation advantages to quickly reach major ports. We specialize in developing and manufacturing all sorts of prefabricated modular houses which are used for construction site dormitories, hotels, shops, offices, carports, portable toilets, and living houses.
The standard domestic dimensions for modular homes are 6 meters in length, 3 meters in width, and 2.9 meters in height. For export, the common dimensions are 6 meters in length, 2.4 meters in width, and 2.9 meters in height. Our products include various functional modules (e.g., shower modules, restroom modules, meeting room modules, etc.), which can be freely combined to meet the majority of client application needs. Additionally, we offer customization in size, appearance, and functionality to meet clients' unique aesthetic and functional requirements.
The lifespan of modular homes varies depending on the type. Based on different customer use cases, these homes can meet the needs of both temporary and semi-permanent buildings:
• Prefabricated homes: Typically used for accommodation, offices, and storage, they can last 5-20 years depending on customer requirements.
• Container homes: With broad applications, their typical lifespan is 8-15 years depending on the environment, while specially designed ones can last up to 25 years.
• Light steel villas: Usually applied in rural homes, cultural tourism accommodations, and high-end camp housing, these semi-permanent structures can last up to 50 years when treated with professional techniques.
The standard design of our products meets basic load parameters, with a wind pressure tolerance of 0.45KN/㎡, equivalent to resisting winds of up to level 10. If the environment at the project site is harsh and has higher wind pressure, the standard structure needs to be reinforced. Typically, reinforcement measures fall into two categories: structural reinforcement of the house (e.g., increasing load-bearing components like beams and columns or key nodes) and external structural assistance (e.g., adding anti-wind cables, reinforcing enclosure materials, and increasing the density of self-tapping screws).
Our modular housing products can withstand an earthquake intensity of 8 degrees, equivalent to a seismic resistance rating of 6.4 magnitude. In the event of an earthquake, the light steel structure has better flexibility, effectively reducing the impact of destruction and minimizing harm to occupants.
The structural and enclosure systems of our housing products use A-grade fireproof materials that comply with standards and meet the fire safety requirements of international regulations.
All of our housing series have excellent waterproof and leak-proof performance. Our prefabricated and light steel villa products have corresponding structural waterproofing and leak-proofing techniques. For container homes, we use a four-corner centralized drainage system. Through water spray testing, when the drainage system is unblocked, it can handle a rainfall rate of 16mm/min, which is equivalent to moderate to heavy rain. If local rainfall is high or frequent, we recommend adding a double-sloped roof and switching from centralized drainage to roof drainage to help reduce rain noise.
